QTJ6 15 QT6 15 block making machine hydraulic hollow block machine price

Product Description

1. ---

   1. QT6-15 Fully Automatic Stacking Brick Making Machine Plant use PLC intelligent control, make the man-machine interface as true, control system equipped with complete logic control, production program, malfunction diagnosis system and remote control function.
   2. Can produce the paver block with or without color on the surface, if need color, should use the face-color material feeding device.
   3. Through mold-releasing oil cylinder, the mold box was locked into the vibration table with high rigidity to reach the synchronous vibration, so that the concrete can be fluidified and exhausted in two or three seconds to en-sure the high-density,especially suitable to produce the standard blocks, which can be piled up immediately so that the pallet investment can be saved directly.



   Features:



   The body uses thick - walled square tubes and an ultra - long guide sleeve to ensure that the body is firm, shock - resistant, and the pressure head runs accurately.

   Vibrating pressure separation technology, install a vibrating support plate, and at the same time, install a secondary pressure head and a shock - absorbing rubber pad to completely isolate the vibration pressure interference.

   Adopt PLC induction intelligent control system, program interlocking and reliable operation.

   Use imported hydraulic solenoid valves to ensure reliable operation of the hydraulic system and extremely low failure rate.



CLICK HERE TO CONTACT US

Specification

Item	Block size(mm)	Pcs/ mould	Pcs/ Hours	Pcs/ 8 Hours
Hollow block	390x190x190	7	1260-1680	10080-13440
Hollow block	390x140x190	8	1440-1920	11520-15360
Standard brick	240*115*53	36	6480-8640	51840-69120
Paver bricks	200x100x60	20	3600-4800	28800-38400
