Large capacity 120m3 ready mixed concrete batching plant price
Product Description
Aggregate Storage Bin
Aggregate batching machine includes cumulative / single measurement batching way which mainly for sand , stone
Aggregate Pre-storage Bin
Aggregate storage bin could have aggregate material ready for once mixing , in order to improve the production efficiency
Powder Silo
Powder silo mostly for cement , flyash and mineral powder material
Additive Storage Bin
Additive storage bin is use for additive material storage water common comes from water well or lake
Flat Belt Conveyor
Use for aggregate material transmission after batching and weighing
Lifting Hopper
Use for loading the aggregate material into mixing system
Inclined Belt Conveyor
Use for loading the aggregate material into mixing system
Conveying System
Use for transmission of powder material from storage into mixing system
Single Measurement
There is a measuring hopper below each type of aggregate bin, and three tension sensors are hung through suspension bolts for weighing
Cumulative Measurement
There is only one measuring hopper under the aggregate bin, and four tension sensors are hung through suspension bolts for weighing
Single Measurement
The powder is transported to the powder measuring hopper through a screw conveyor and weighed by sensors on the measuring hopper
Water Metering Bucket
Directly transport water to the water metering hopper through a submersible pump
Additive Metering Hopper
Transport water to the metering hopper through sewage pump
Control Room, Electric Control Cabinet, Operation Console
With the function of ratio storage, automatic compensation of drop, compensation of sand and stone moisture content (sand and stone moisture content tester needs to be ordered separately), it can accurately and conveniently input, adjust and modify the set value and formula number of each material
Product Details
Specification
|
Model
|
HZS25
|
HZS35
|
HZS50
|
HZS60
|
HZS75
|
HZS90
|
HZS120
|
HZS150
|
HZS180
|
|
Discharging Capacity (L)
|
500
|
750
|
1000
|
1000
|
1500
|
1500
|
2000
|
2500
|
3000
|
|
Charging Capacity(L)
|
800
|
1200
|
1600
|
1600
|
2400
|
2400
|
3200
|
4000
|
4800
|
|
Maximum Productivity(m³/h)
|
25
|
35
|
50
|
60
|
75
|
90
|
120
|
150
|
180
|
|
Charging Model
|
Skip Hopper
|
Skip Hopper
|
Skip Hopper
|
belt conveyor
|
Skip Hopper
|
belt conveyor
|
belt conveyor
|
belt conveyor
|
belt conveyor
|
|
Standard Discharging Height(m)
|
1.5~3.8
|
2~4.2
|
4.2
|
4.2
|
4.2
|
4.2
|
3.8~4.5
|
4.5
|
4.5
|
|
Number of Species of Aggregate
|
2~3
|
2~3
|
3~4
|
3~4
|
3~4
|
4
|
4
|
4
|
4
|
|
Maximum Aggregate Size(mm)
|
≤60mm
|
≤80mm
|
≤80mm
|
≤80mm
|
≤80mm
|
≤80mm
|
≤120mm
|
≤150mm
|
≤180mm
|
|
Cement/Powder Silo Capacity(set)
|
1×100T
|
2×100T
|
3×100T
|
3×100T
|
3×100T
|
3×100T
|
4×100T or 200T
|
4×200T
|
4×200T
|
|
Mixing Cycle Time(s)
|
72
|
60
|
60
|
60
|
60
|
60
|
60
|
30
|
30
|
|
Total Installed Capacity(kw)
|
60
|
65.5
|
85
|
100
|
145
|
164
|
210
|
230
|
288
|
