LB1500 Asphalt batching Plant 120ton asphalt mixing plant for sale

Short Description:

Asphalt mixing station refers to the complete set of equipment used for mass production of asphalt concrete, which can produce asphalt mixture, modified asphalt mixture and color asphalt mixture.

Price: 198000-258000USD

Previous: 10Ton asphalt mixing plant asphalt plant manufacturers

Next: LB1300 Asphalt batching Plant 100ton asphalt plant supplier

Product Detail

Product Tags

Product Description

It mainly consists of batching system, drying system, combustion system, hot material lifting, vibrating screen, hot material storage bin, weighing mixing system, asphalt supply system, powder supply system, dust removal system, finished product silo and control system.

CLICK HERE TO CONTACT US

Specification

Model	Rated Output	Mixer Capacity	Dust removal effect	Total power	Fuel consumption	Fire coal	Weighing accuracy	Hopper Capacity	Dryer Size
SLHB8	8t/h	100kg	≤20 mg/Nm³	58kw	5.5-7 kg/t	10kg/t	aggregate;±5‰ powder;±2.5‰ asphalt;±2.5‰	3×3m³	φ1.75m×7m
SLHB10	10t/h	150kg		69kw				3×3m³	φ1.75m×7m
SLHB15	15t/h	200kg		88kw				3×3m³	φ1.75m×7m
SLHB20	20t/h	300kg		105kw				4×3m³	φ1.75m×7m
SLHB30	30t/h	400kg		125kw				4×3m³	φ1.75m×7m
SLHB40	40t/h	600kg		132kw				4×4m³	φ1.75m×7m
SLHB60	60t/h	800kg		146kw				4×4m³	φ1.75m×7m
LB1000	80t/h	1000kg		264kw				4×8.5m³	φ1.75m×7m
LB1300	100t/h	1300kg		264kw				4×8.5m³	φ1.75m×7m
LB1500	120t/h	1500kg		325kw				4×8.5m³	φ1.75m×7m
LB2000	160t/h	2000kg		483kw				5×12m³	φ1.75m×7m
