Product Description

1. ---

   - “one-trailer-mounted ” continuous asphalt mixing plant is optimized and redesigned based on our stationary continuous asphalt mixing station

   and semi-mobile continuous asphalt mixing station.

   - “one-trailer-mounted ” continuous asphalt mixing plant realizes the high integration of asphalt plant, and one transport trailer can realize

   all the functional requirements of the asphalt mixing station (filling, drying, mixing, storage of finished products, operation),

   which meets the user's requirements for fast installation, fast transition, and rapid production.

   - Up to now, our “one-trailer-mounted ” continuous asphalt mixing plant” has been exported to Europe, Africa, North America etc.

   The convenience of fast transportation, transfer, and rapid recommissioning greatly saves the costs and improves the construction efficiency.

CLICK HERE TO CONTACT US

Specification

Model	Rated Output	Mixer Capacity	Dust removal effect	Total power	Fuel consumption	Fire coal	Weighing accuracy	Hopper Capacity	Dryer Size
SLHB8	8t/h	100kg	≤20 mg/Nm³	58kw	5.5-7 kg/t	10kg/t	aggregate;±5‰   powder;±2.5‰   asphalt;±2.5‰	3×3m³	φ1.75m×7m
SLHB10	10t/h	150kg		69kw				3×3m³	φ1.75m×7m
SLHB15	15t/h	200kg		88kw				3×3m³	φ1.75m×7m
SLHB20	20t/h	300kg		105kw				4×3m³	φ1.75m×7m
SLHB30	30t/h	400kg		125kw				4×3m³	φ1.75m×7m
SLHB40	40t/h	600kg		132kw				4×4m³	φ1.75m×7m
SLHB60	60t/h	800kg		146kw				4×4m³	φ1.75m×7m
LB1000	80t/h	1000kg		264kw				4×8.5m³	φ1.75m×7m
LB1300	100t/h	1300kg		264kw				4×8.5m³	φ1.75m×7m
LB1500	120t/h	1500kg		325kw				4×8.5m³	φ1.75m×7m
LB2000	160t/h	2000kg		483kw				5×12m³	φ1.75m×7m
