qtj4 26c block making machine manual concrete block machine

Product Description

1. ---

   1. Key Features:

      • Semi-Automatic Operation: The QTJ4-26C is a semi-automatic machine, meaning it requires minimal manual intervention for operation, significantly reducing labor costs while ensuring efficiency and quality.
      • High Production Capacity: Capable of producing up to 4,000 blocks per day, this machine is ideal for small to medium-scale block production.
      • Durable Construction: Built with robust steel components, the QTJ4-26C is designed for long-lasting durability, even under harsh operating conditions.
      • Flexible Molding Options: The machine offers flexible mold changes to accommodate various block sizes and designs, providing versatility in production.
      • Energy Efficiency: The machine is engineered for energy-efficient operation, which helps reduce power consumption and operational costs.

      Applications: The QTJ4-26C Block Making Machine is ideal for producing concrete blocks used in construction, landscaping, and civil engineering projects. It is commonly used to manufacture foundation blocks, walls, paving stones, and other prefabricated concrete products.



      The machine's ease of use, combined with its cost-effective production capabilities, makes it an excellent choice for businesses looking to enter or expand in the block manufacturing industry. The detailed manual included with the machine covers installation, operation, maintenance, and troubleshooting, ensuring optimal performance and reducing downtime.



      Design and Structure:

      • The machine features a robust and compact design, allowing it to be easily installed and operated in different construction sites.
      • It is built with a steel frame and utilizes advanced welding technology, ensuring durability and stability during operation.
      • The machine consists of a main machine body, a concrete mixer, a belt conveyor, a stacker, and a control system.

   2. Block Production Capacity:

      • The QT4-24 machine can produce various types of concrete blocks, including solid blocks, hollow blocks, interlocking paver blocks, and curbstones.
      • It has a production capacity of around 4,000 to 5,000 blocks per 8-hour shift, depending on the block size and design.

   3. Operation and Control:

      • The machine is semi-automatic, requiring manual labor for loading raw materials and unloading finished blocks.
      • It is equipped with a control panel that allows for easy operation and adjustment of block dimensions and production parameters.
      • The control system ensures precise and consistent block production, resulting in uniform block sizes and shapes.







CLICK HERE TO CONTACT US

Specification

Block size	Qty/mold	Cycle time	Qty/Hour	Qty/8 hours
Hollow block 400x200x200mm	4 pcs	26-35s	410-550pcs	3280-4400pcs
Hollow block 400x150x200mm	5pcs	26-35s	510-690pcs	4080-5520pcs
Hollow block 400x100x200mm	7pcs	26-35s	720-970pcs	5760-7760pcs
Solid brick 240x110x70mm	15pcs	26-35s	1542-2076pcs	12336-16608pcs
Holland paver 200x100x60mm	14pcs	26-35s	1440-1940pcs	11520-15520pcs
Zigzag paver 225x112.5x60mm	9pcs	26-35s	925-1250pcs	7400-10000pcs
