QT4-25C QTJ4-25 automatic block machine fully automatic block making machine price

Product Description

1. ---

   • QT4-25 block machine is one of our newly designed block making machines. With less power, it achieves super strong vibration. It adopts full automatic spiral material laying method, so the material in the mould is well-distributed. With simple operation and high productivity, when producing hollow blocks, it has an advantage over the large hydraulic block machines.

Applications:

Fully automatic,

Raw materials are generally cement, sand, gravels, crushed stone powder, slags, fly ash, ect, depending on customers' choice.

A. 8-10% cement, 30-40% sand, 50-60% crushed stone

B. 8-10% cement, 30% flyash, 60% sand or stone powder The diameter of sand and stones need to be less than 15mm, if produce paver interlocking brick, need color iron.

QTJ4-25 Main Technical Parameter
1	Molding Pieces	4 pcs/mold (390*200*200 Hollow Brick)	5	Vibration Frequency	4200r·pm
2	Molding Cycle	25 seconds	6	Exciting Power	45KN
3	Power	20.6Kw	7	Pallet Size	850x450mm
4	Dimension	5600x2240x2400mm	8	Brick output method	Automantic

● The QTJ4-25 brick making machine is a computer automatic model developed by our company based on large hydraulic machinery. It has a classic vibration mode and is particularly suitable for producing high-strength blocks, standard bricks, etc.
● Adopting PLC computer intelligent control, with fault alarm and display functions, absorbing various advantages of similar hydraulic models, reasonable price, simple operation, sturdy and durable
● Automatic feeding, automatic fabric distribution, automatic scraping, automatic board distribution, electric decoupling, can be equipped with a dedicated code plate machine, can stack 3-5 layers high, and use a dedicated pulling cart to remove bricks, greatly reducing the labor intensity of workers and achieving fully automated production of small block machines. Suitable for large-scale production of blocks in small and medium-sized block factories.
● Short molding cycle and high efficiency.
● The dedicated high-efficiency vibrator for the Taiwan vibration machine has strong excitation force and better compaction effect of the product. Large molding area, capable of producing various types of cement products, with a wide production range.
● Compulsory mechanical positioning, fast and uniform step feeding, precise and consistent products.

CLICK HERE TO CONTACT US

Specification

---

Pallet Size	880x550mm
Qty/mold	4pcs 400x200x200mm
Host Machine Power	21kw
Molding cycle	25-30s
Molding method	Vibration
Host Machine Size	6400x1500x2700mm
Host Machine Weight	3500kg
Raw materials	Cement, crushed stones, sand, stone powder, slag, fly ash, construction waste etc.
