QT4-25C automatic block moulding machine hydraulic block making machine price

Product Description

1. ---

   • Automatic Operation: The QT4-25C features an advanced automatic control system, reducing labor costs and ensuring a smooth, uninterrupted production process. It integrates PLC control with human-machine interface (HMI), making it user-friendly and easy to operate.



   • Efficient Vibration System: Equipped with a powerful vibration motor, the machine ensures even compaction of the concrete mix, resulting in high-quality blocks with excellent strength and durability. The vibration system also minimizes the energy consumption required for block production.



   • Flexible Molding Options: The QT4-25C can produce a wide range of block sizes and shapes, including hollow blocks, solid blocks, paving stones, and other customized designs. Its versatile mold configuration allows for easy switching between different block types to meet market demands.



   • Hydraulic Pressure System: The machine uses hydraulic pressure to achieve maximum block compaction and density, ensuring the blocks are strong, durable, and uniform in appearance.



   • High Productivity: With an output capacity of up to 4,000 blocks per day (depending on block size and production settings), the QT4-25C is ideal for medium to large-scale production operations. It allows manufacturers to produce high volumes of quality blocks in a short amount of time.



   • Durability and Stability: Constructed with high-quality steel and advanced materials, the QT4-25C is built to last, with long service life and minimal maintenance requirements. Its solid frame structure ensures stability during operation, even under heavy load conditions.



   • Low Power Consumption: Despite its high productivity, the QT4-25C operates efficiently with low energy consumption, making it an environmentally friendly and cost-effective option for block production.

CLICK HERE TO CONTACT US

Specification

Block size	Qty/mold	Cycle time	Qty/Hour	Qty/8 hours
Hollow block 400x200x200mm	4pcs	25-30s	480-576pcs	3840-4608pcs
Hollow block 400x150x200mm	5pcs	25-30s	600-720pcs	4800-5760pcs
Hollow block 400x100x200mm	7pcs	25-30s	840-1008pcs	6720-8064pcs
Solid brick 240x110x70mm	20pcs	25-30s	2400-2880pcs	19200-23040pcs
Holland paver 200x100x60mm	14pcs	25-30s	1680-2016pcs	13440-16128pcs
Zigzag paver 225x112.5x60mm	12pcs	25-30s	1440-1728pcs	11520-13824pcs
