Gantry Type Block cuber machine brick collect machine

Product Description

1. ---

2. The Brick Cuber Machine is an essential part of modern brick and block production lines, designed to automatically collect, arrange, and stack finished bricks or blocks into neat, uniform cubes. After the curing or drying process, bricks are transported to the cuber station, where the machine uses synchronized arms, clamps, or vacuum systems to accurately pick and place products according to programmed stacking patterns.

3. 1. Adopts PLC control unit and double hydraulic control, two clamping head work at the same time, more quickly and efficiently.

2. 2. Equip with different machine models with different block and pallet size, the stacked block be transported by forklift after separated to the curing area, and the pallet will be used for the production again.
   3. It is designed according to customers block shape and pallet size.

Working Principle

1. Brick Loading
   Bricks are fed onto the conveyor after drying or curing.

2. Positioning and Detection
   Sensors detect the position of bricks for accurate gripping.

3. Gripping and Lifting
   The gripper mechanism picks a set number of bricks from the conveyor.

4. Stacking
   Bricks are placed layer by layer in a predefined cube pattern on a pallet or platform.

5. Cycle Repeat
   The process repeats until the desired height or number of bricks per cube is achieved.

6. Final Handling
   Completed cubes are moved to the packaging or storage area, often by forklifts or automated guided vehicles (AGVs).



   Advantages

   • Increased Productivity: Automates collect blocks and make the blocks to be a cube, significantly reducing handling time.
   • Fast speed: about 12s can collect one pallets blocks, also can collect two machines at one time.
   • Labor Cost Savings: Fully automatic operation by the machine and reduces labor working to lower operational costs.
   • Improved Safety: Minimizes the risk of injury by workers block handling.
   • Space saving: Neatly stacked blocks use space more efficiently in storage and transportation.
